3211822 PT 6-PE Feed-through Terminal Block Phoenix

3211822 PT 6-PE Feed-through Terminal Block Phoenix
1. Tool-Free Push-In Feed-Through PE Wiring
This Phoenix 3211822 PT 6-PE grounding terminal adopts advanced push-in spring connection, supporting 0.5–10mm² wires (AWG20–8). Direct wire insertion finishes wiring without screwdrivers, drastically boosting cabinet assembly efficiency. Built-in elastic metal clips maintain constant clamping force, avoiding loose grounding caused by mechanical vibration for long-term stable equipotential bonding.
2. Standard Green-Yellow Safe Grounding Structure
Classic green-yellow flame-retardant PA66 housing complies with global PE identification norms, rated 1000V with 8kV surge withstand capacity. Tinned brass conductive strips deliver ultra-low resistance for reliable fault current conduction. UL94 V0 fireproof material effectively prevents circuit breakdown and fire hazards in industrial low-voltage systems.
3. Universal DIN Rail Modular Compatibility
8.2mm compact single-level design fits standard NS35 DIN rails for quick snap-on installation. Modular splicable layout matches cross jumpers, marker tags and end stops seamlessly. Widely applied in automation control panels, power distribution cabinets and machinery equipment for standardized protective earthing wiring.
